G32-SP Ultra-Precision Universal Grinding Center

G32-SP Ultra-Precision Universal Grinding Center

Engineered for Medical, Orthopedic & Robotics Manufacturing Excellence The G32-SP is not just a grinder; it’s a precision manufacturing system designed to meet the extreme tolerances, complex geometries, and superior surface integrity demanded by the world's most advanced industries. For manufacturers of surgical instruments, artificial joints (hip/knee stems), spinal implants, robotic actuators, and miniature high-precision components, it delivers unparalleled accuracy, flexibility, and process reliability. Why the G32-SP is the Choice for Critical Applications Uncompromising Precision for Life-Saving Devices: Achieves ≤ 1.5 µm roundness and ≤ Ra 0.4 µm surface finish, meeting and exceeding the stringent requirements for implantable medical devices and friction-critical robotic components. HEIDENHAIN 0.1µm encoders and SIEMENS 828D CNC provide the nano-level control needed for micro-features on surgical tools and delicate robot parts. Superior Stability for Challenging Materials: The hydrostatic X-axis and rigid T-bed structure eliminate stick-slip, ensuring vibration-free grinding of difficult-to-machine materials like titanium alloys, cobalt-chrome (CoCr), ceramics, and stainless steels commonly used in orthopedics and robotics. Integrated thermal management (bed cooling, spindle chiller) guarantees consistent accuracy over long production runs—critical for batch consistency in medical device...
阅读更多
A2003828-280

A2003828-280

HSK-A100 / BBT50 High-Torque & High-Speed Dual-Winding Spindle (220V)A2003828 | 305 N·m / 12,000 rpm | 280mm | Mitsubishi-Wound Motor | For HMCs & Gantry Mills The A2003828 is a high-performance dual-winding electric spindle engineered for demanding applications on horizontal machining centers and gantry mills. Built with a robust 280mm housing and compatible with both HSK-A100 and BBT50 tool systems, it delivers exceptional versatility through its 220V, Mitsubishi-wound asynchronous motor. Operators can select high-torque mode (Y-connection: 305 N·m at 1500 rpm max) for heavy roughing, or switch to high-speed mode (Δ-connection: 12,000 rpm at 184 N·m) for productive milling and finishing. Designed for high rigidity, minimal thermal growth, and seamless integration with Mitsubishi drives via its native serial encoder, this spindle is a powerful upgrade for shops tackling large, challenging workpieces. Technical Overview This spindle is engineered to master both high-force and high-speed machining in one robust package. Its core strength lies in the specialized Mitsubishi-wound dual-coil design, which provides two distinct power curves optimized for different materials and...
阅读更多
A2005282-280

A2005282-280

HSK-A100 / BBT50 High-Torque & High-Speed Dual-Winding Spindle305 N·m / 12,000 rpm | 280mm | Flange Mount | 380V | Compatible with Siemens & 3rd-Party Drives The A2005282 is a powerful and versatile dual-winding electric spindle engineered for heavy-duty horizontal machining centers and gantry mills. Featuring a robust 280mm housing and dual HSK-A100/BBT50 tool interface compatibility, it delivers exceptional flexibility through its dual-winding asynchronous motor. Operators can select high-torque mode (Y-connection: 305 N·m, 1500 rpm max) for demanding roughing, or high-speed mode (Δ-connection: 12,000 rpm, 184 N·m) for efficient milling and finishing. Designed with a flange for vertical mounting orientation, high structural rigidity, and optimized thermal management, it is an ideal performance upgrade for 380V systems using Siemens or other third-party drives alongside its native Mitsubishi encoder interface. Technical Overview This spindle is a strategic solution for workshops requiring both immense cutting force and high-speed capability in a single unit. Its core design balances massive torque for heavy stock removal with the speed needed for productivity, all within a...
阅读更多
A2002051-230

A2002051-230

A2002051 High-Torque Dual-Winding Spindle for Mitsubishi SystemsBBT50 | 210 N·m Torque | 230mm | Certified for Seamless Mitsubishi Integration The A2002051 is a high-performance, dual-winding electric spindle designed for robust vertical or horizontal machining centers operating within the Mitsubishi CNC ecosystem. Built with a 230mm housing and a BBT50 tool interface, it delivers exceptional torque and power flexibility through its dual-winding (Y/Δ) motor—offering either 210 N·m of high torque for heavy cutting or 26 kW of power for efficient milling. Pre-configured for Mitsubishi controls and drives, and engineered with high rigidity (1000 N/µm radial stiffness), this spindle ensures reliable, precision performance for demanding industrial applications. Technical Overview This spindle is engineered to provide strategic machining flexibility, allowing operators to choose between high-torque and high-power modes based on material and operation requirements. Its certified compatibility with Mitsubishi CNC and drive systems guarantees straightforward integration and stable servo performance. Combined with high structural stiffness and effective thermal management, it is ideal for workshops seeking to enhance capability and uptime on Mitsubishi-controlled...
阅读更多
A2005701-230

A2005701-230

A2005701 High-Torque Dual-Winding Spindle for Mitsubishi SystemsHSK-A100 | 210 N·m Torque | 230mm | Certified for Seamless Mitsubishi Integration The A2005701 is a formidable, dual-winding electric spindle engineered to deliver exceptional torque and versatility for heavy-duty vertical machining centers and gantry mills within the Mitsubishi control ecosystem. Featuring a robust 230mm housing and an HSK-A100 tool interface, it offers strategic performance flexibility through its dual-winding (Y/Δ) motor, providing either 210 N·m of high torque for challenging materials or 26 kW of power for efficient milling. Pre-configured and certified for Mitsubishi CNC and drive systems, and built with extreme rigidity (1000 N/µm radial stiffness), it guarantees plug-and-play reliability and precision for demanding large-part manufacturing. Technical Overview This spindle is designed as a versatile powerhouse for vertical applications, offering machine shops the ability to optimize cutting strategy based on material and operation. Its core strength lies in combining substantial torque output with the assurance of seamless integration into the Mitsubishi automation environment. The certified compatibility eliminates setup complexity, while the high rigidity...
阅读更多
A2004861-230

A2004861-230

A2004861 High-Torque Dual-Winding Spindle for Fanuc SystemsHSK-A100 | 210 N·m Torque | 230mm | 220V Dual Winding | Optimized for Heavy-Duty Horizontal Machining The A2004861 is a powerful, dual-winding electric spindle engineered for demanding heavy-duty milling and boring applications on large horizontal machining centers (HMCs) and floor-type boring mills. Built with a substantial 230mm housing and a robust HSK-A100 tool interface, it delivers exceptional 210 N·m of torque in Star (Y) connection from a 220V dual-winding motor fully compatible with Fanuc drive systems. Designed for horizontal installation and equipped with integrated high-pressure through-spindle coolant (7 MPa), this spindle combines immense cutting force, superior rigidity, and process cooling to maximize productivity in machining high-strength alloys and large components. Technical Overview This spindle is designed as a high-torque specialist for horizontal applications, where stability and powerful cutting force are paramount. The 220V dual-winding (Y/Δ) configuration offers strategic flexibility, allowing the same spindle to operate as an ultra-high-torque unit for tough materials or a higher-power unit for efficient milling. Its compatibility with Fanuc controls and...
阅读更多
A2004191-230 (Y/Δ)

A2004191-230 (Y/Δ)

A2004191 Ultra-High-Torque Short-Nose Spindle with HSK-A100206 N·m Torque | 35 kW | Engineered for Maximum Rigidity & Access in Heavy-Duty Machining The A2004191 represents the pinnacle of heavy-duty spindle design, engineered for the most demanding milling applications on large gantry mills, floor-type boring machines, and powerful machining centers. Built with a massive 230mm diameter and a robust HSK-A100 tool interface, its dual-winding (Y/Δ) motor unleashes a colossal 206 N·m of torque for conquering the toughest materials, while maintaining 35 kW of power. The innovative short-nose design provides superior workpiece access, and when combined with exceptional rigidity (1000 N/µm radial stiffness), an immense 45,000 N drawbar force, and integrated high-pressure coolant, it defines a new standard for productivity and capability in large-part manufacturing. Technical Overview This spindle is engineered as a true powerhouse, prioritizing extreme torque delivery and structural integrity above all else. The "short-nose" configuration minimizes overhang, bringing the tool closer to the bearing support for unmatched rigidity and allowing access to deep cavities or confined workspaces on large components. Designed for...
阅读更多
A2001961-190 (Y/Δ)

A2001961-190 (Y/Δ)

A2001961 High-Torque Dual-Winding Spindle with HSK-A100Heavy-Duty Power for Large Tool Machining | 81 N·m Torque | 22 kW Power The A2001961 is a robust, high-torque electric spindle engineered for heavy-duty milling applications requiring the use of large-diameter tools and substantial cutting force. Built around a formidable HSK-A100 tool interface within a 190mm housing, its dual-winding (Y/Δ) motor offers strategic flexibility: delivering 81 N·m of high torque for challenging materials or 22 kW of power for efficient high-feed operations. Featuring an exceptionally high drawbar force of 45,000 N for utmost tool security, this vertical-mount spindle is designed for stability and productivity in large-part machining on gantry mills and powerful vertical machining centers. Technical Overview This spindle is purpose-built for shops that utilize large face mills, slotting cutters, and other substantial tooling on tough materials. The HSK-A100 interface provides the rigidity and precision necessary for heavy-load power transmission. The dual-winding design allows operators to prioritize either immense cutting force or maximum power efficiency, making it a versatile core component for demanding industrial milling tasks. Core Performance...
阅读更多
A2001760 Heavy-Duty Grinding Spindle

A2001760 Heavy-Duty Grinding Spindle

A2001760 Heavy-Duty Grinding Spindle190mm | 90 N·m Torque | Engineered for High-Precision, High-Rigidity Grinding Applications The A2001760 is a professional-grade electric spindle designed specifically for demanding grinding machines, such as cylindrical grinders, roll grinders, and large surface grinders. Built with a robust 190mm housing, it delivers exceptional torque (up to 90 N·m) and rigidity (1000 N/µm radial stiffness) necessary for stable, high-precision material removal on hardened steels, alloys, and large workpieces. Featuring ultra-precision bearings and optimized for horizontal installation, this spindle is the core component for achieving superior surface finishes, tight tolerances, and reliable performance in industrial grinding operations. Technical Overview This spindle is engineered from the ground up for the unique challenges of grinding, prioritizing process stability, thermal control, and precision over high rotational speed. Its high torque output and extreme radial stiffness minimize vibration and deflection during the grinding process, which is critical for achieving fine surface finishes and maintaining geometric accuracy on large or heavy components. Core Performance Advantages High Torque & Power for...
阅读更多
A2004711-190 (Y/Δ)

A2004711-190 (Y/Δ)

A2004711 Ultra-High-Torque Spindle for Mitsubishi SystemsBBT50 | 143 N·m Max Torque | 190mm | Redefining Heavy-Duty Cutting with Extreme Rigidity The A2004711 is engineered for a singular purpose: to deliver unmatched torque and structural integrity for the most demanding heavy-duty milling applications on large vertical machining centers and gantry mills within the Mitsubishi ecosystem. While sharing a similar 190mm outer diameter with other models, its design philosophy diverges significantly, prioritizing extreme torque (143 N·m) and maximum rigidity (1000 N/µm radial stiffness) over raw high-speed power. Equipped with a robust BBT50 tool interface and fully certified for Mitsubishi CNC systems, this spindle is the definitive solution for stable, powerful machining of high-strength materials where cutting force and process stability are non-negotiable. Technical Overview & Key Differentiator The A2004711 distinguishes itself within the 190mm spindle class by being a dedicated ultra-high-torque, high-rigidity specialist. Unlike models optimized for high power or dual-mode versatility, this spindle's core is built around a massive bearing configuration and a motor winding designed to generate immense, stable torque...
阅读更多
